Civil 3D - Setting up a title block with dynamic fields for plan production

Using ATTSYNC and ATTDEF commands in Civil 3D to create text boxes for a title block that will be controlled by a sheet set manager. Use this functionality to make plan production more efficient and productive. These steps are some of the first needed to create a template for sheet set plan production. Chapters 0:00 Introduction 0:11 Creating a sheet set and sheet set manager (SSM). 0:43 Import sheet into sheet set. 0:51 Sheet set custom properties. 1:35 Adding attribute definition fields (ATTDEF). 2:27 Adjusting attribute definition field names. 2:45 Creating a block to get the attribute definitions to function (BLOCK). 3:05 Multiple sheets in a sheet set. 3:24 Editing the attribute definition block (ATTSYNC). 3:51 Adding field to attribute definition block. 4:11 Subscribe and Like :D
