Civil, Survey Plan Reading Utility Plans

The utility plan sheet in the plan set distinguishes between drainage systems, typically referred to as drainage or storm sewer, and utilities like sanitary sewer, electrical, water, and gas. The legend includes proposed elements such as sanitary, underground electric, telephone, water service, construction fence, and fiber optics, alongside existing infrastructure. A detailed view highlights features like an electrical riser, a sanitary pump station, and a grease trap, which vary based on the structure's intended use. The plan provides a layout for utility placement, crucial for those responsible for staking and locating utilities, depending on the utility contractor's requirements. Post-installation, utilities may need to be located for as-built documentation or integration into a Geographic Information System (GIS) for local authorities. The subsequent page focuses on sanitary sewer profiles, detailing the layout of the pump station, grease trap, and the elevations of both existing and proposed ground levels. These profiles are integral to the project's development, ensuring proper utility installation and alignment with the overall design.
