FreeCAD: How to Unfold a More Complex Model For 2D Export From A Problematic Imported IGS File

Unfolding a 3D object to 2D in FreeCAD is essential for cutting on a Laser or plasma or any other fabrication method that requires a 2D output. There are a number of workflows available but with this model with have a object that is similar to something that has been made in a sheet metal process so we have to unwrap it in a specific way. With this IGS model I have also introduced a number of errors; flipped normals, non manifolds etc and I show you three ways to over come the problems of invalid offsets and analyzing and fixing the output. #FreeCAD , #CAD , #3DPrinting Journey with me and Patreon   / mangojellysolutions   Donate: https://ko-fi.com/mang0 https://www.paypal.com/paypalme/darre... Subscribe:    / @mangojellysolutions   Browse my Redbubble Shop: http://MangojellyLabs.redbubble.com Blog: https://mangojellysolutions.blogspot....
