PIC16F877A interface LM35 temperature sensor project tutorial using MikroC code & Proteus demo.

Guys, My lectures are free for everyone. If you want to support my channel, then become a Youtube member by following link below:    / @learningmicrocontrollers3561   Seek knowledge from the cradle to the grave /// /////////////////////////////////////////////////////**********************************///////////////////////////////// Hello guys, Welcome to Learning Microcontrollers youtube Channel, Guys I have also compiled course on Udemy as well. Where you will learn under my direct supervision in a more supervised way. Here is the links to the courses I have on Udemy, By taking any of these courses you will be supporting my channel aswell. This will help me to make more videos with better hardware in the future. I hope you look forward to it. Courses Links: 1- https://www.udemy.com/course/pic16f87... 2- https://www.udemy.com/course/mikroc-f... 3- https://www.udemy.com/course/mikroc-f... 4- https://www.udemy.com/course/pic-micr... 5- https://www.udemy.com/course/learn-ar... ///////////////////////////////////////////////////// Hello guys, This tutorial is about how to interface an LM35 sensor with a PIC16F877A microcontroller and it displays output on a 16x2 LCD. Demonstration is on proteus software. Become a Patreon and support my channel using link below: https://patreon.com/user?u=81261678 How to setup PIC hardware video link:    • Setting up a PIC16F877A/PIC16F887/PIC18F****   How to setup Lm016 16x2 LCD video link:    • PIC16F877A interface Lm016 16x2 JHD LCD. U...   Code of current video is as under: // Lcd pinout settings sbit LCD_RS at RC0_bit; sbit LCD_EN at RC1_bit; sbit LCD_D7 at RD1_bit; sbit LCD_D6 at RD0_bit; sbit LCD_D5 at RC3_bit; sbit LCD_D4 at RC2_bit; // Pin direction sbit LCD_RS_Direction at TRISC0_bit; sbit LCD_EN_Direction at TRISC1_bit; sbit LCD_D7_Direction at TRISD1_bit; sbit LCD_D6_Direction at TRISD0_bit; sbit LCD_D5_Direction at TRISC3_bit; sbit LCD_D4_Direction at TRISC2_bit; float temp; char temp1[6]; float celcius; void main() { LCD_init(); Delay_ms(500); ADC_init(); Delay_ms(500); Lcd_Cmd(_LCD_CURSOR_OFF); Delay_ms(100); Lcd_Cmd(_LCD_CLEAR); Delay_ms(100); while(1) { temp = ADC_read(0); Delay_ms(50); celcius = ((temp * 5.0)/1024) * 100; Delay_ms(50); floattostr( celcius , temp1 ); Delay_ms(50); LCD_OUT(1,1, "Temp = " ); LCD_OUT(1,9, temp1); LCD_OUT(1,16, "C"); Delay_ms(100); } }
