Havila Saturn

Havila Saturn outbound from the Port of Aberdeen, Scotland on 13th May 2010. Shiptype Anchor Handling Tug Supply IMO 9378175 MMSI 258155000 Call Sign LACM Flag Norway Port of Registry Fosnavaag Owner : Havila Saturn KS - Norway Operator: Havila Shipping ASA - Norway Built : 2008-02 Cemre Muhendislik Gemi Insaat Sanayi ve Ticaret Ltd Sti-Pendik (Hull) 2008-02 Havyard Leirvik AS - Leirvik i Sogn Yard/hull No.: 092 Standard design:Havyard 842; Hull Material:Steel; Hull Connections:Welded; Decks:1 dk; Bulbous bow; Ice strengthened Length Overall 74.500 Length (BP) 64.800 Breadth Extreme 17.600 Breadth Moulded 17.200 Draught 5.500 Depth 8.000 Gross Tonnage (GT) 2,806 Net Tonnage (NT) 857 Deadweight (DWT) 2,859 Formula Deadweight 3,936 Main Engine : Design: MaK, Engine Builder: Caterpillar Motoren GmbH & Co. KG - Germany 2 x 12M32C, 4 Stroke, Single Acting, Vee 12 Cy. 320 x 420, Mcr: 6,000 kW (8,158 hp) at 750 rpm 2 oil engines with clutches, flexible couplings & single reduction reverse geared to screw shafts driving 2 CP propellers at 140 rpm Total Power: Mcr 12,000kW (16,316hp) Max. Speed: 18.00kts, Service Speed: 15.00kts Thrusters: 1 Thwart. CP thruster (f) 883kW(1,201bhp) , 1 Thwart. CP thruster (a) 883kW(1,201bhp) , 1 Retract. directional thruster (f) 883kW(1,201bhp)
