High-Speed, Flexible Connector Assembly Automation

Flexibility, speed, and ingenuity in one connector assembly line! This 5-component system features four Asyril flexible feeders, enabling quick changeovers between dissimilar product groups. Five 6-axis robots from STÄUBLI Robotics ensure precise, efficient part handling, while vision inspection from Keyence maintains top-tier quality — any nonconforming assemblies are automatically segregated at the end of the line. A walking beam transfer system minimizes cycle time while delivering smooth, accurate movement throughout the line. The obvious standout: a ferris wheel mechanism that flips sub-assemblies while allowing side installation —maximizing space and versatility. The unseen MVP: a hidden lower rail brings the upper and lower sub-assemblies together seamlessly with a bottom-up press - tucked neatly within the rail itself. This system is a true testament to the engineers, builders, and programmers at MS Automation—made possible by the outstanding products and support from our dedicated partner suppliers. 👏 Let us know what stands out to you!
