2890 = 1 -2 LEIFELD - PNC 75 - Spinning Dishing Forming Drueckmaschine Druckmaschine Forceer скачать в хорошем качестве

2890 = 1 -2 LEIFELD - PNC 75 - Spinning Dishing Forming Drueckmaschine Druckmaschine Forceer

LEIFELD metal spinning Make : Leifeld Germany Typ : PNC 75 Age : 1994 Serial : 10 . 3320 . 0 Bed length : 2.425 Max. swing Ø : 750 Max. length : 825 Max. centre height : 350 Support stroke X : 450 Support cross Z : 255 Force support X : 28 kN Force support Z : 28 kN Hydr. Ejector : 200 mm Force ejector : 28 kN Spindle head : DIN 55027 – Gr.6 Spindle speeds : 300 – 1150 – 2400 3000 Feed support : 10 M/Min Feed pinole : 12 M/Min Approach Feed tailstock : 13 M/Min Return speed tailstock : 25 M/Min Leifeld LEICO CNC with playback System unit Leifeld KA System unit Leifeld BAE I Bought from 1e owner lower hours ! Please Note: The above information has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
