Overclock Mod GBA SP [insideGadgets ClkxCtrl]

I am using ClockxControl from insideGadgets to repair a non-functioning SP motherboard that was damaged in an attempt to overclock. I originally installed this over clock mod in a Micro here:    • Overclockable Game Boy Micro [ClockxContro...   Later removed that mod to replace with a one-off custom here:    • InsideGadgets Game Boy Micro Overclock Mod...   Stock is come and go for ClockxControl but may be purchased direct from iG here: https://shop.insidegadgets.com/produc... Wiring in the AGS is identical to the AGB except that the clock test pad is on the opposite side of the board (can still be used). It's easier to use the top (closest to edge of board) crystal pad instead. Board placement upside-down between the RAM and cart slot seems to be the best spot. I had to clip a small "+" support off of the rear housing battery compartment to get everything to fit. I used enameled magnet wire to make running the button control wires easier. Here are some pics of my install: https://imgur.com/a/6J2beAr See the AGB instructions on the item listing for the pinout on both sides. (picture direct link: https://shop.insidegadgets.com/wp-con... ) also, 44:00 for LED mod for those that keep asking --- Game Boy Wiki: https://gameboy.github.io/ Need personalized help? Try joining one of the many discord servers linked in the wiki. I do not respond to emails or DMs with troubleshooting requests. My test ROM packs for GB(A): 240p Test Suite: https://github.com/pinobatch/240p-tes... mattcurrie's color test and scrolling bar test: https://mattcurrie.com/gb-lcd-tests.zip and "AGS Aging" for GBA button test and LCD calibration Continuously updated backlight power usage and brightness spreadsheet: https://drive.google.com/open?id=1wUs... Tools I regularly use (and recommend) Fine point tweezers - Engineer PTN-03: https://retrogamerepairshop.com/produ... Mini power supply - Miniware MDP-XP: https://retrogamerepairshop.com/produ... Solder sucker - Engineer SS-02: https://retrogamerepairshop.com/colle... MiniWare TS80P Soldering Iron: https://retrogamerepairshop.com/colle... Tips for TS80P (J02 and K4): https://retrogamerepairshop.com/colle... MiniWare MHP30M Mini Hot Plate: https://retrogamerepairshop.com/produ... Amtech Soldering Flux: https://retrogamerepairshop.com/colle... Through Hole solder practice kit: https://retrogamerepairshop.com/colle... Surface mount solder practice kit: https://retrogamerepairshop.com/colle... The links provided are NOT affiliate links. I have a new affiliate code for RGRS, however. Use code "makho" at checkout for 10% off your order or if you'd like to support me directly, I've created a ko-fi: https://ko-fi.com/makho
