LUSAS modelling and results/reporting overview for a 3-span box structure

An initial import of a DXF and an IGES file showing automatic meshing and rendering facilities is followed by line beam modelling of a 3-span box beam structure. The assignment of user-defined section properties is shown for standard, linear and tapered box sections, and a method for finding model geometry without material assigned is highlighted. Results are viewed for bending moments and stresses both on the fleshed model and in a tabular results format. A report is created showing user-defined outputs and how saved views of the model and results are automatically updated each time a report is created. For better quality video playback visit www.lusas.com
