Make a SMD FM Transmitter

Buy me a coffee: I spent a lot of time on my videos on YouTube ,I have had this YouTube account 20 years ! and my recent videos I have built projects that are controlled by microcontrollers and need code to make them run ,the code takes a lot of time to get right and work well then I even share my code to anyone that wants it,I would appreciate a coffee if you can. Regards Darren,buy me a coffee at this link : https://buymeacoffee.com/dazaro In this video we are showing you how to make a FM transmitter Bug using 2 transistors and small SMT 805 parts This FM transmitter Bug is very easy to build. The size of the circuit board is ONLY 20mm x 15mm. I design the circuit board layout using Pain shop pro X2 ,it takes me 2 hours to get the design right ,i want a very small PCB. To make the PCB i will be using the toner transfer method and Ferric Chloride. Parts used: Home made PCB ,20mm X 15mm SMD 2N3904 transistors x 2 All capacitors and resistors are SMT 805 1nf ceramic capacitor 10pf ceramic capacitor 33pf ceramic capacitor 22nf axial ceramic capacitor x 2 1 - 5p to 30p air trimmer 470R resistor 10K resistor 47K resistor 68K resistor 1M resistor 10mm Mic 175cm antenna Battery Plug Some solder
