Part 1: Fluke 1773 PQ Anaylzer | I40s El CT & PT Connection in MVSG(13.8KV) | LV Compartment

Welcome to our channel! In this video, we explain how I40s El Current Transformers (CTs) and Potential Transformers (PTs) are connected inside the LV compartment of a Medium Voltage (MV) switchgear panel. Topics Covered: What is an IS40 El CT? Purpose of CTs and PTs in MV Switchgear Step-by-step CT wiring in LV compartment PT connection with MVSG with LV compartment Practical tips from on-site experience CT (Current Transformer) Connections: Installed in LV compartment on core balance or busbars Used for protection, metering, and relaying Secondary wiring connected to protection relays PT (Potential Transformer) Connections: Connected to Medium Voltage switchgear with LV Compartment via drawout modules Voltage signal brought to LV panel through terminal blocks Used for voltage measurement and protection functions Important Note: Always follow IEC/SASO standards and site-specific wiring diagrams. Use proper tagging, ferrules, and insulation 🔔 Don’t forget to Like, Share, and Subscribe for more electrical videos, site installation guidance, and testing procedures! #ElectricalEngineering #MediumVoltage #Switchgear #CTWiring #PTConnection #IS40El #LVCompartment #ProtectionRelays #MVPanel #SiteWork #PowerDistribution #fluke #Fluke1773powerqualityanalyzer #Multivoltengineering
