India’s Semiconductor Master Plan, launched through the ₹76,000-crore India Semiconductor Mission (ISM) 1.0 in 2021, aims to end near-total chip import dependence and build domestic manufacturing, starting with mature 28nm chips through major projects like Tata-PSMC and Micron, along with packaging, design incentives, and workforce development, marking India’s first real entry into chip production. However, recognizing that fabs alone are not enough, ISM 2.0 (Budget 2026–27) shifts focus toward strengthening the entire ecosystem by investing in local supply chains, chip design IP, electronics components, and R&D via SCL Mohali modernization and ₹40,000-crore component incentives, ensuring India controls materials, tools, and technology, not just factories. While India already plays a major global role in advanced chip design—including Qualcomm’s 2nm chip contributions—the long-term roadmap targets manufacturing self-sufficiency by 2029 and eventual entry into advanced 3nm–2nm production by 2035, transforming India from a chip importer into a fully integrated semiconductor power. 00:00 – India’s current chip fab status and Mohali facility 00:08 – Tata fab and why India is starting with 28nm 00:20 – Demand for 28nm/40nm chips in cars, appliances, and 5G 01:01 – Micron facility progress for memory chips 01:09 – Tata-Intel partnership and Qualcomm automotive chips 01:45 – Semiconductor Mission 2.0 and reducing imports 02:15 – Local production of gases and electronic components 02:41 – India’s target for 3nm by 2032 and 2nm by 2035 03:03 – India’s chip design talent and 2nm tape out 03:45 – Dhruva 64 automotive chips and EV goals 04:17 – MediaTek R&D center in Noida 04:31 – Renesas working on 3nm design in India 04:50 – India compressing decades of chip learning 05:57 – Qualcomm’s second-largest R&D center in India 06:19 – Cost of fabs and Tata’s $10B investment 06:42 – Telecom R&D like Wi-Fi and 6G 07:10 – India’s role in AI and Google Gemini 07:48 – India scaling like smartphone manufacturing boom #IndiaSemiconductor #Semiconductor #ChipManufacturing #MakeInIndia #DigitalIndia #IndiaTech #SemiconductorMission #ISM2_0 #ChipWar #SiliconIndia X - https://x.com/utsavtechie Instagram - / utsavtechie #Techie Images and Video Clips used in this video are belong to their respective owners. These are only used to explain the concept clearly to viewers.Copyright Disclaimer: - Under section 107 of the copyright Act 1976, allowance is made for FAIR USE for purpose such as criticism, comment, news reporting, teaching, scholarship and research. Fair use is a use permitted by copyright statues that might otherwise be infringing. Non- Profit, educational or personal use tips the balance in favor of FAIR USE.
