Siemens NX Revolve Command Tutorial | Create Complex HPDC Components

Master the Siemens NX Revolve command in this comprehensive Hindi tutorial. Whether you are designing a simple cylindrical part or a complex die-casting mold insert, understanding the Revolve feature is essential for efficient 3D modeling. In this lesson, we break down the NX Revolve interface, covering everything from axis selection to advanced Boolean operations. As a die-casting designer, using Revolve correctly can save hours of modeling time when creating circular cooling channels or rotating mold components. 🕒 Key Chapters (Timestamps) [00:00] Introduction to NX Revolve Command [00:15] How to Select Sections and Regions [00:52] Defining the Vector (Axis) and Origin Point [01:55] Understanding Limits: Angles and 'Until Selected' [03:15] Boolean Operations: Unite, Subtract, and Intersect [05:15] Creating Sheet Bodies vs. Solid Bodies [05:41] Advanced Offset Settings (1-Sided vs. 2-Sided) [07:45] Practical Examples: Creating Open Profiles In your current Die Casting projects, do you find yourself using the Revolve command more for mold inserts or for the actual part design? Let me know in the comments! 👇
