Segment Routing TE | Multi-Domain IGP | PCC-PCE Controller| BGP-LS | Cisco IOSXR | ASR900 Lab Part-1

Part-2 link    • Segment Routing TE | Multi-Domain IGP | PC...   Segment Routing TE | Multi-Domain IGP | PCC-PCE Controller| BGP-LS | Cisco IOSXR | ASR900 Lab Part-2 Config is same for AS2 nodes and PE1 & ASBR1 config avilable in Part1 description RR1/PCC config router bgp 1 bgp router-id 11.11.11.11 router bgp 1 bgp unsafe-ebgp-policy router bgp 1 address-family ipv4 unicast router bgp 1 address-family ipv4 unicast network 11.11.11.11/32 router bgp 1 address-family vpnv4 unicast router bgp 1 address-family link-state link-state router bgp 1 neighbor 1.1.1.1 router bgp 1 neighbor 1.1.1.1 remote-as 1 router bgp 1 neighbor 1.1.1.1 update-source Loopback0 router bgp 1 neighbor 1.1.1.1 address-family vpnv4 unicast router bgp 1 neighbor 1.1.1.1 address-family vpnv4 unicast route-reflector-client router bgp 1 neighbor 22.22.22.22 router bgp 1 neighbor 22.22.22.22 remote-as 1 router bgp 1 neighbor 22.22.22.22 update-source Loopback0 router bgp 1 neighbor 22.22.22.22 address-family ipv4 unicast router bgp 1 neighbor 22.22.22.22 address-family link-state link-state router bgp 1 neighbor 33.33.33.33 router bgp 1 neighbor 33.33.33.33 remote-as 2 router bgp 1 neighbor 33.33.33.33 ebgp-multihop 5 router bgp 1 neighbor 33.33.33.33 update-source Loopback0 router bgp 1 neighbor 33.33.33.33 address-family vpnv4 unicast router bgp 1 neighbor 33.33.33.33 address-family vpnv4 unicast next-hop-unchanged router bgp 1 neighbor 33.33.33.33 address-family link-state link-state router isis CORE1 is-type level-2-only router isis CORE1 net 49.1930.1680.0002.00 router isis CORE1 distribute link-state router isis CORE1 address-family ipv4 unicast router isis CORE1 address-family ipv4 unicast metric-style wide router isis CORE1 address-family ipv4 unicast mpls traffic-eng level-2-only router isis CORE1 address-family ipv4 unicast mpls traffic-eng router-id Loopback0 router isis CORE1 address-family ipv4 unicast segment-routing mpls router isis CORE1 interface Loopback0 router isis CORE1 interface Loopback0 address-family ipv4 unicast router isis CORE1 interface Loopback0 address-family ipv4 unicast prefix-sid index 11 router isis CORE1 interface GigabitEthernet0/0/0/0 router isis CORE1 interface GigabitEthernet0/0/0/0 point-to-point router isis CORE1 interface GigabitEthernet0/0/0/0 address-family ipv4 unicast router isis CORE1 interface GigabitEthernet0/0/0/1 router isis CORE1 interface GigabitEthernet0/0/0/1 point-to-point router isis CORE1 interface GigabitEthernet0/0/0/1 address-family ipv4 unicast segment-routing global-block 16000 17000 pce address ipv4 11.11.11.11 router static address-family ipv4 unicast 2.2.2.2/32 Null0
