☑️14 - Mesh Analysis with Voltage Sources

In this lesson, we shall learn how to solve circuits problem using mesh analysis considering circuits with voltage sources. A loop is any closed path in a circuit, while A mesh is a loop that does not contain any other loop within itself. The current in a mesh is called a mesh current In this lesson we shall solve two examples. Steps to solve circuits using mesh analysis 1. Assign mesh currents in the circuit 2. Apply kvl at each mesh and use ohms law to express the voltages in terms of mesh currents. 3. Solve the equations obtained simultaneously, if the equations obtained are more than two, it is preferred to use cramer's rule or matrix inversion method while you can use method of elimination and substitution for two equations. NB: the number of meshes gives an indication of the number of equations you are going to obtain. 00:00 - Mesh Analysis 03:31 - Example 1 11:05 - Example 2 Playlists on various Course 1. Applied Electricity    • APPLIED ELECTRICITY   2. Linear Algebra / Math 151    • LINEAR ALGEBRA   3. Basic Mechanics    • BASIC MECHANICS / STATICS   4. Calculus with Analysis / Calculus 1 / Math 152    • CALCULUS WITH ANALYSIS / CALCULUS 1 / MATH...   5. Differential Equations / Math 251    • DIFFERENTIAL EQUATIONS   6. Electric Circuit Theory / Circuit Design    • ELECTRIC CIRCUIT THEORY / CIRCUIT DESIGN   Make sure to watch till the end. Like, share, and subscribe. Thank you.
