0057: Custom EEPROM Replacement | 16-Bit Computer From Scratch

Description* I have a problem. 256 k-bit (32 k-Byte) EEPROM are no longer produced and are quite expensive. Considering the number of EEPROM I will need for the control logic, this is not going to work. In this video I tackle the EEPROM problem, creating a custom replacement using SRAM. As you may have come to expect with my videos, it does not go perfectly. I learn a lot about diodes and currents along the way. Please see the following link for more information. https://www.autodesk.com/products/fus... Chapters: 0:00 Intro 2:07 The Starting Point 3:51 SRAM 4:59 The Plan 7:47 Component Review 8:35 Diode Specs and Choice 11:22 "Mock-Up" 14:59 Shop Work 16:53 Preparing the Strip Board 18:49 Initial Assembly 22:15 Cleaning Up My Mess 24:41 Pull-Up Resistor 25:47 Final Solder-Up 27:02 Sanity Checks 28:57 Stepping Back and Other Corrections 31:16 The Testing Deteriorates 32:55 Diode Explanation (?) 36:46 Replacing the Diode 38:05 Testing the New Diode 40:00 Wrap-Up Resources: 16-Bit Computer From Scratch Complete Playlist: https://www.youtube.com/watch?list=PL... ALU Playlist:    • Arithmetic Logic Unit   Clock Module Playlist:    • Clock & Reset Modules   Register Module Playlist:    • Register Module   Intruction Cycle Playlist:    • Instruction Cycle Modules   Memory Module Playlist:    • Memory Module   KiCad Playlist:    • KiCad Design   Assembler Source Code: https://github.com/eryjus/asm/tree/v0... Control Logic Source Code: https://github.com/eryjus/control-log... Simple Test Source Code: https://github.com/eryjus/16BCFS-test... CircuitVerse Project Link: https://circuitverse.org/users/160845... Additional Tags: #Homebrew #Breadboard #PCB #KiCad #74LS #IC #SMD #schematic #CircuitVerse
