25" ARTER HORIZONTAL SPINDLE ROTARY SURFACE GRINDER

https://www.machineryvalues.com/inven... 25" ARTER HORIZONTAL SPINDLE ROTARY SURFACE GRINDER MODEL: B-24 S/N: 56-3581 NEW: 1956 HYDRAULIC TABLE, RAM RECIPROCATION, POWER AUTO UPFEED OF THE TABLE TABLE TILTS +/- 10 DEGREES FOR CONCAVE & CONVEX GRINDING MAX. SWING INSIDE GUARDS .......................... 36" VERTICAL CAPACITY UNDER FULL 20" WHEEL ............ 8" TILT OF TABLE FOR CONVEX OR CONCAVE GRINDING ...... 10 DEG. GRINDING WHEEL SIZE ......................... 20"D X 12"BORE X 2"WIDTH CHUCK ROTATION SPEED .............................. 37 TO 150 RPM GRINDING WHEEL SPINDLE SPEED ...................... 950 RPM HANDWHEEL FOR RAISING & LOWERING WORK TABLE IS CALIBRATED IN INCREMENTS OF .................. 0.005" FINE FEED KNOB FOR RAISING & LOWERING WORK TABLE IS CALIBRATED IN INCREMENTS OF .................. 0.0001" APPROXIMATE MACHINE WEIGHT ........................ 10,700 LBS EQUIPPED WITH: 25" DIAMETER CONCENTRIC POLE ELECTRO-MAGNETIC CHUCK *** EXCEPTIONAL CHUCK LIFE *** VERY LATE "MAGNA-LOCK USA" MODEL CC-115-500 (S/N: 111420) 500 WATT NEUTROFIER FOR THE ELECTRO-MAGNETIC CHUCK REMOTE VARIABLE HOLD CHUCK CONTROL EXTERNAL COOLANT PUMP WITH TANK 10 H.P. "DELCO" MOTOR FOR THE SPINDLE, 3/60/220-440 VOLTS MACHINE IS PRESENTLY WIRED FOR 460 VOLTS MACHINE FEATURES: HYDRAULICALLY POWERED WHEEL SLIDE TRAVEL POWER AUTOMATIC UPFEED OF THE TABLE HYDRAULICALLY POWERED CHUCK ROTATION MANUAL TILTING OF WORK TABLE FOR GRINDING INTERNAL OR EXTERNAL TAPER SURFACES EXTERNAL HYDRAULIC SYSTEM ** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE ** ** EXCELLENT CONDITION & APPEARANCE **
