How to add dimensions to a drawing in BricsCAD

How to add dimensions to a drawing in BricsCAD. After completing this video, you will be able to: • Determine the size and location of objects with dimensions • Use a dimension style to control the appearance of dimensions in a drawing • Use dimensions to quantify objects in a drawing • Find the horizontal or vertical distance from one point to another • Show the linear distance between two points regardless of the relative angle • Find the relative angle between the two lines • Determine the exact length of an arc • Apply a radius to an arc or a circle • Apply a diameter to an arc or circle • Identify the center of an arc or circle using a Center Mark • Create a series of dimensions based on an existing dimension • Determine the distance between a start point and multiple items following a baseline • Create dimensioning in a drawing for multiple objects simultaneously Download your free, no-obligation 30-day trial now: https://www.bricsys.com/bricscad/?utm...
