Polymer Modified Bitumen Production Equipment | Full System Overview

This equipment is designed for the production of polymer modified bitumen, powered by a three-phase 380V, 50Hz electrical system. The complete system includes three major components: 🔹 Part 1: 5 m³ Vertical Bitumen Tank Heating Method: Diesel oil burner (direct heating) Vertical slow-speed mixer, 5.5 kW Insulated bitumen pump, 5.5 kW, flow rate: 8 m³/h Equipped with bitumen filter and a 2-inch three-way valve for switching between internal and external circulation 🔹 Part 2: Colloid Mill Motor power: 22 kW Maximum capacity: 6 m³/h Grinding fineness: 0.1–0.5 µm Operating temperature: up to 260°C 🔹 Part 3: Thermal Oil Furnace (Heat Tracing System) Provides hot thermal oil for heat tracing of bitumen pump, colloid mill, three-way valve, and pipelines Includes frame, electric heating tubes, thermal oil pump, valves, sensors, etc. Automatic ON/OFF control based on thermal oil temperature range 🔧 Optional: Screw Conveyor Available Upon Request This system is ideal for contractors and manufacturers involved in road construction, bitumen modification, and high-viscosity bitumen handling. 👉 For more details or to request a quote, feel free to contact us. #bitumenproduction #modifiedbitumen #polymerbitumen #bitumenplant #colloidmill #thermalfurnace #asphaltequipment
