Material Cutout in Revit * Cutout Map Material Tutorial *

Get these Project files and all Advanced 1h Courses:   / balkanarchitect   Subscribe for more! Please Like this video! In this video i show you how to use the material cutout option in material browser in revit. It starts of in Photoshop where the base image that is used for the brick material (but you cn use this for any other material) is duplicated to be made black and white for the bump map and a new layer is made for the cutout map. What is black on this layer is a void and what is white is left as your base image. In Revit the image is loaded in the material that is made by duplicating the "Default" material. After that the scale is set and the bump map as well as the cutout map images are loaded in and set to the same scale as the base material image. After all of this is completed you can use the material in your projects! Additional Tags: Material, Browser, cutout, map, bump, brick material, Revit, Architecture, House, Reference Plane, Detail Line, Floor,, BIM, Building Information Modeling. Building, Roof, Roof by element, Roof by extrusion, How to model a roof in revit, Revit City, Revit 2018, Revit Turorials, Revit 2017, Revit Autodesk, Revit Architecture 2017, Revit Array, Render, AutoCAD, How to model in Revit, learn Revit, Revit Biginner tutorial, Revit tutorial for Beginner, Revit MEP, Revit Structure,
