1000W INVERTER 6 IRF3205 use IR2153

This is a very simple 12V to 220V inverter. It uses IR2153 IC, You can buy this IC at the store for very cheap price, about 1.5 $ for 5 ICs. It needs few electronic components. you only need 1 capacitor and 1 resistor for the IC. IC will be ready to work. I have used 6 IRF3205 mosfet for this project, it has maximum power of 1000W. Normally it can work at 600W which almost does not heat up. It uses 12V 0 12V to 220V transformer. You can adjust the frequency with the potentiometer. or change capacitor value. Although simple, it also has the ability to cut when the battery is low, when the battery voltage is below 9V. IC stopped working. However it has no voltage feedback. If large loads are used, the voltage will decrease. All my projects are free, I design them on EAGLE 6.0. I uploaded it to Google drive. You need to use a web browser to download the file and open the file with winrar software (extract) on the PC. Open schematic file (.SCH) and PCB file (.BRD) with EAGLE software. Hope you enjoy my videos and projects. Like, share and don't forget to subscribe to my channel. one more thing, thanks to everyone, my channel has reached 50K subscribers. Facebook group : http://bit.ly/CreativeElectronic Diagram here : File 45 in http://bit.ly/AllLink You need web browser to download file (I upload it to google drive), open the file with winrar on PC. I use EAGLE 6.6 to design the PCB. #Inverter #12Vto220V #1000W
