3D Printing - Working on slicer settings and print quality

Let's try to print 15 teeth M3 size pulley The pulley on the left side is printed with advanced settings left auto and the one on right side is printed after manual tuning of perimeter width. everything else is identical, same printer same slicer, same model, same filament etc.. Manualy adjusting / fine tuning perimeter width is very important to get the best result. If you leave it auto in "Advanced Settings" section then the nozzle will jump across each gear tooth tying to fill-in tiny gaps and this will ruin the print quality! The perimeter width is affected by nozzle size, layer height, extruder speed and print speed. It is also a bit experimanltal so that you should check visualy the "print-tool-path" after each time you alter the perimeter width. When you see that the external and internal perimeters are adjacent and no more tiny fill-ins exist then you are good to go. For further in dept information I recommend you to check the article "Slic3r - Advanced perimeter tuning - 3D Printing tutorial" at http://richrap.blogspot.com.tr/2015/0...
