Metamaterial Shell Snapthrough Demo (Ansys Mechanical APDL)

I'm working from home today, where I don't have access to the Ansys Mechanical license used by the school, which is why this is the student edition. My input code (there is a lot of other code in use here to generate the sim): ! Inputs m = 1/5 ! ratio of height of cross-section (NOTE: CELL ELEMENT CROSS-SECTION) to rise of arch (more or less) n = 2 lambda = 1/50 ! ratio of rise to length eta = 1/5 ! ratio of width to length cwr = 1/50 ! ratio of cell length to shell length chr = 2/1 ! ratio of cell depth to cell length case = 1 ! metamaterial cell type a = 1 ! rise of the arch k = 20 ! iteration resolution constant. higher = better resolution, longer time taken to simulate zeta = 1/15 ! non dimensional damping multiplier tau = 150 ! non dimensional timing of each load step fps = 45 ! animation frames per second ! Constants Ex = 10000e3 ! mother material modulus of elasticity prxy = 0.31 ! mother material poisson's ratio rho = 0.0975 ! mother material density
