Hydraulic Schematic Line Types Explained (ISO 1219)

Hydraulic schematics use different types of lines — and they don’t always represent connections. In this free preview lesson from Hydraulic Schematics 101, you will learn how to correctly interpret the different line types used in hydraulic diagrams and why context matters when reading them. In this lesson we cover: • Work lines (main connection lines) • Pilot lines and how they operate valves • Drain lines in closed loop systems • Enclosure lines and multi-component housings • How to identify connected vs. non-connected intersections • The ISO 1219 convention for line connections You will also learn how pressure relief valves are operated through pilot lines and how adjustable spring-loaded symbols are represented in schematics. Understanding line types is one of the most important steps in learning how to read hydraulic diagrams confidently. This is a free preview from the full course: Hydraulic Schematics 101 A practical course focused on understanding and reading hydraulic schematic diagrams — without heavy math or complex calculations. 👉 Full course link: https://www.udemy.com/course/hydrauli... If you want to truly understand hydraulic systems, start with the lines. #hydraulicsystems #hydraulics #engineering #fluidmechanicsandhydraulicmachines #hydraulicengineering
