ME1507 Motor with Kelly KLS96601-8080IPS Controller - Complete Setup Guide for Basic Operation

In this video I carry out a bench test of the Motenergy ME1507 motor with the Kelly KLS96601-8080IPS controller. I cover all steps needed to get the motor turning including the 12-volt system, high-voltage wiring, contractor setup, pre-charge resistor, connecting the motor to the controller, wiring of the controller electronics, and basic programming the controller to identify the hall angle and set the motor direction. This guide will show you everything you need to get the motor spinning for the first time! There is an addendum to this video where I correct some mistakes I made. Check it out here:    • ME1507 Bench Test Addendum - Addressing so...   Need help with your build? Schedule a consult https://calendly.com/gaiusgarage 0:00 Intro 0:49 Main components 1:49 12V system 4:32 Controller hi-voltage wiring 5:28 Controller electronics wiring 7:52 Hall sensor connector on the motor side 10:24 Programming dongle 11:09 Contactor wiring 11:45 Turning the system on 12:32 Connecting to the configuration software 13:52 Basic motor settings 14:42 Reading the sine/cosine encoder signal 17:47 Calculating the Zero-point & Amplitude values 21:22 Entering the ZP & Amplitude values in the configuration program 22:28 Performing the angle identification procedure 27:59 Turning the motor 31:42 Changing the motor direction ME1507 Motor http://motenergy.com/mepmbrmo.html ME1507 spec sheet https://sep.yimg.com/ty/cdn/yhst-1293... KLS-8080/IPS controller https://kellycontroller.com/shop/kls-... KLS-8080/IPS User manual https://kellycontroller.com/wp-conten... Configuration Software (All KLS controllers - PC) https://kellycontroller.com/wp-conten... Sine/Cosine Monitoring Software for KLS-8080/IPS controller (PC) https://kellycontroller.com/wp-conten... SM-4A to USB dongle https://kellycontroller.com/shop/sm-4... Driver for SM-4A to USB dongle https://kellycontroller.com/wp-conten... 600A Contactor (I'm using 12V version) https://kellycontroller.com/shop/zjw-... 2kOhm 20W Precharge resistor https://www.ebay.com/itm/221736623376... Delphi Metri-pack 150 8-pin Female connector (the one on ME1507 motor) https://www.customconnectorkits.com/1... Delphi Metri-pack 150 8-pin Male connector https://www.customconnectorkits.com/1... Male and Female pins for Delphi Metri-pack 150 connectors https://www.customconnectorkits.com/1... https://www.customconnectorkits.com/1... 9-way connector on KLS controller https://kellycontroller.com/shop/9-pi... #electricmotorcycles #ebike #diy #motorcycles #lithiumionbatteries #diyebike #motorcycles #caferacer #dirtbike #electricvehicle #motorcontroller #kellycontroller #diytutorial Music from Uppbeat (free for Creators!): https://uppbeat.io/t/adi-goldstein/i-... License code: RXSQGH7BZT7VHHF8
