Adding ethernet to a Raspberry Pi Zero using the GPIO pins (and not the USB port)

To buy the ethernet module for your Raspberry Pi Zero, just search for ENC28J60 on Ebay. Connection-scheme for the ENC28J60 on the Raspberry Pi Zero: clk = not connected wol = not connected si = GPIO10 cs = GPIO8 vcc = +3.3v gnd = 0v / gnd rst = not connected sck = GPIO11 so = GPIO9 nt / int = GPIO25 To configure the Raspberry Pi Zero, do the following on the command line: $ sudo raspi-config Go to "9 Advanced Options", select "SPI" and Enable it. edit /boot/config.txt Add the line: dtoverlay=enc28j60 That's it. If you want a static MAC-address so that the IP-address does not change at each startup, do the following: Create the following file: /lib/systemd/system/setmac.service Add the following contents: [Unit] Description=DSet the MAC address for the ENC28J60 enet adapter at eth0 Wants=network-pre.target Before=network-pre.target BindsTo=sys-subsystem-net-devices-eth0.device After=sys-subsystem-net-devices-eth0.device [Service] Type=oneshot ExecStart=/sbin/ip link set dev eth0 address 00:00:00:00:00:00 ExecStart=/sbin/ip link set dev eth0 up [Install] WantedBy=multi-user.target Replace the "00:00:00:00:00:00", by a MAC-address of your choice, but keep the first pair of zero's. Then do this: $ sudo chmod 644 /lib/systemd/system/setmac.service $ sudo systemctl daemon-reload $ sudo systemctl enable setmac.service
