The Making of an ADC DAC board for FPGA

This series of videos are about a Hobby project which I'm working on, is a over the average hobby level but still achievable by many of us. The main idea is build a board that I can attach to my FPGA board (Zedboard) for sampling radio signals and synthesizing signals too. The ADC has a sample rate of 80Mhz (125Msamples ADC are available footprint compatible) and a resolution of 14 Bits. The output of the ADC is LVDS going to the FPGA. The DAC is a dual 14 Bit DAC from TI which cam be used as two independent channels or in a I/Q format. The DAC clock is 500Msamples. The following episodes are about the construction and start up of the board (if it works) you can find the schematics on my blog page https://www.adaptivedesign.ie/post/ad... Enjoy the video!
