Aerospace Prepreg Towpre Narrow Tape Slitting Machine | CFRP Composites

#slittingmachine #automatedfiberplacement #cfrp How to contact Jota Machinery: Web: www.jotamachinery.com E-mail: jotamachinery@gmail.com WhatsApp: +86-13868814910 Official website: https://www.jotamachinery.com/ Facebook:   / jotamachinery   LinkedIn:   / jotamachinery   Instagram:   / jotamachinery   Chapter of Aerospace Prepreg Towpre Narrow Tape Slitting Machine | CFRP Composites 00:00 glassfiber prepreg ud tape spooling 00:17 3-inch air expanding shaft 00:20 glassfiber unidirectional tape 00:24 automatic web guide system 00:31 backside of narrow tape slitting machine 00:34 PE film peel-off device 00:38 6.35mm slitting blade 00:43 slitting effect 00:46 glassfiber slitting 01:07 guide wheel 01:11 HMI touch screen 01:19 spooling system 01:38 glassfiber prepreg tape spooling 01:44 spooling effect Specification data of JT-SLT-250S narrow tape slitting machine Max unwinding width: 250mm Max. unwinding Diameter:650mm Unwinding shaft: 3-inch or 6-inch air-expanding shaft Slitting width: 3.175mm/0.125″, 6.35mm/0.25″ and 12.7mm/0.5″ Thermoset unidirectional prepreg tape: 50m/min Thermoplastic glass fiber ud tape :100m/min Max spooling height : 300mm Splicing function ： yes Nowadays, there are two types of automated fiber placement: prepreg towpre and dry fiber tow, and the width of the material are usually 6.35mm and 12.7mm, with a deviation of about 0.125mm. The application of composite materials in aerospace manufacturing is inseparable from the application of automation equipment, especially automated tape laying technology. The automated fiber placement technology is to bundle the prepreg tow into a belt by the fiber placement head, and lay it according to the planned route. During the placement process, it can turn according to the planned route. , and can achieve opening, reinforcement, and other requirements, the angle deviation is smaller, and the production efficiency and quality are improved. During the placement process, the prepreg filaments can be individually controlled and placed according to the actual situation. Automatic wire laying technology has been used in Boeing aircraft, military aircraft, etc., and can improve the quality and efficiency of manufacturing. For example, Boeing 787, Boeing 737 A350, and military aircraft F-22 have all adopted automatic wire laying technology in manufacturing. Without automated fiber placement technology, it is difficult to manufacture large passenger aircraft, and it is difficult to complete technologies such as S-shaped air inlets. Therefore, automated fiber placement technology has important strategic significance and plays a vital role in the aerospace manufacturing industry. About Jota Machinery: Jota Machinery is the leading CFRTP/CFRT/CFRP narrow tape slitting machine manufacturer. After our continuous development and upgrading we have published various machines for thermoplastic composite material: JT-CFRT-650 continuous fiber-reinforced thermoplastic sheets production line:    • What is Continuous Fiberglass Reinforced T...   PEEK+carbon fiber/fiberglass unidirectional tape slitting machine:    • CFRTP Thermoplastic Carbon Fiber UD Tape S...   Traverse spooling machine:    • What is Thermoset Carbon Fiber Epoxy Prepr...
