How is a Lifting Door with Lifting Door Chain Reverse Unit E from item installed? Instructions

This video shows how to assemble the modular Lifting Door with Lifting Door Chain Reverse Unit E from item. How does the item Lifting Door work? The Lifting Door is a ready-to-use solution consisting of coordinated components. It can be flexibly configured, implemented up to a width of 2000 mm and runs particularly smoothly thanks to its chain drive with counterweight. A fall protection device ensures safety. Tip: Choose between manual operation or automation with an electric motor. What are the advantages at a glance? Individual configuration Up to 2000 mm wide Chain drive with counterweight Integrated fall protection Manual or electric operation FAQ Maximum size? Up to 2000 mm wide. Safety features? Fall protection and counterweight. Can it be automated? Yes, with an electric motor. Areas of application? Mechanical engineering and systems with high safety and ergonomic requirements. Video content for installation at a glance: 00:00 Intro The image shows a fully installed, manually operated lifting door. 00:04 Step 1: Lifting door element The frame made of Clamp Profile 8 40x40 is partially assembled, the transparent panel is inserted and fixed with clamping strips. Screw tightening: A/F 5 mm (14 Nm), A/F 3 mm (10 Nm). 01:02 Step 2: Arrester and bearing sets The bearing sets and arrester are fastened with special T-slot nuts through holes in the profile (SW 4 mm, 10 Nm). Buffers and handles are attached to the underside. 02:35 Step 3: Chain Assemble to the arrester using flat-nose pliers. 02:58 Step 4: Guide and installation Connect guide profiles with automatic fasteners (A/F 5 mm, 14 Nm), attach radii for better running characteristics. Insert lifting door with handle facing downwards; two-person installation is recommended. 03:26 Step 5: Chain reverse units Cut M8x20 threads into the guide profiles, insert the chain and screw the reverse units in place (A/F 6 mm, 32 Nm). Close the frame and fit the stop buffer. 04:32 Step 6: Counterweight Prepare the guide profiles and attach them to the guide rails (A/F 4 mm, 10 Nm). Cut the counterweights to length according to the weight of the door (formula: Length of counterweight in mm = weight of lifting door in kg x 26 mm/kg - 11 mm), insert them into the guide sets and connect them to the chains. 06:56 Step 7: Final assembly Check the function, install the conduit profiles and cover caps. The following products were used in the video: 1. Clamp Profile 6 30x30: http://i24.ws/43111 2. Hexagon Socket Head Cap Screw DIN 912 M6x30, bright zinc-plated: http://i24.ws/8000120 3. Lifting-Door Bearing Set: http://i24.ws/48707 4. Lifting-Door Arrester Set: http://i24.ws/48708 5. Cover Profile 6 24x3, black: http://i24.ws/43936 6. Handle Al 350: http://i24.ws/64401 7. Chain 1/2'': http://i24.ws/60231 8. Lifting-Door Guide Profile 8 80x80: http://i24.ws/48510 9. Profile 8 40x40 light: http://i24.ws/2633 10. Automatic Fastening Set 8 40: http://i24.ws/67284 11. Lifting-Door Chain Reverse Unit E: http://i24.ws/48714 12. Impact Buffer M8 D30x30, black: http://i24.ws/41637 13. Support Profile 80: http://i24.ws/19641 14. Button-Head Screw M6x12, bright zinc-plated: http://i24.ws/8000240 15. T-Slot Nut V 8 St M6, T-Slot Nut V 8 St M6, bright zinc-plated: http://i24.ws/48050 16. Lifting-Door Counterweight 60x40 St: http://i24.ws/48759 m = 18.84 kg/m 17. Lifting-Door Counterweight Guide Set: http://i24.ws/48519 18. Conduit Profile U 80x80 SE: http://i24.ws/48745 19. Conduit Cap 80x80, black: http://i24.ws/19690 20. Self-Tapping Screw DIN 7981 St 4.2x9.5, bright zinc-plated: http://i24.ws/8000013 ► MORE TIPS AND TRICKS FOR ITEM PRODUCTS: https://academy.item24.com --- ► If you enjoyed watching our video or want to tell us what you think, please leave us a comment. --- For more information and to check out example applications showing how you can make your production operations more efficient, subscribe to our channel, or visit us at: ► Website: https://de.item24.com/en ► Shop: https://www.item24.com/en-de/ ► Blog: https://blog.item24.com/en/ ► LinkedIn:   / item-industrietechnik-gmbh   ► Facebook:   / itemworldwide   ► YouTube:    / item24com   #Instructions #tutorial #assembly #lifting door #machine The video was recorded on 2023-03-31 10:00:00.000 and is valid until further notice. The description was updated on 2025-09-16 11:00:00.000. This video was produced by the manufacturer of the products used: item Industrietechnik GmbH Friedenstraße 107-109 42699 Solingen
