Tatra 813 8x8 Kolos - scale truck - Cross RC DC8 - first ride

It is a 1/11 scale model of the Czechoslovak Tatra 813 Kolos 8x8 truck (although the manufacturer of the model declares a 1/12 scale). The model was built from the Cross RC DC8 kit, which I bought in the Belgian MCM Racing shop:https://www.mcmracing.com/en/3-mcm-ra... Including all the breaks, and there were a lot of them, it took me about 8 months to assemble the model. The inspiration for such painting of the model was a photo of a real truck from the article: https://www.nztrucking.co.nz/wheels-o... Tara trucks have a characteristic structure - a central load carrying backbone tube, independent swinging half-axles. They had been produced since 1967 to 1982. The Tatra 813 can tow trailers with a total weight of up to 100 tons. A noticeable characteristic of Tatra trucks is also the fact that the wheels of the unladen vehicle are arranged in the shape of the letter "V". I also put on the model elements that are not available in the kit from the Cross RC manufacturer: winch, reversing light, front marker lights, three additional headlights in the front (one on the roof, two under the front windows), two warning lights on the roof, I added the rear direction indicators in half of the rear lamps. Of course, I also modified the electrics, among other things, I separated the main headlights of the model into separately activated low beam and high beam. My wiring diagram is available at the link: https://drive.google.com/file/d/14YkL... The original front suspension seemed too firm to me, so I replaced the springs of the auxiliary telescopic shock absorbers. A video with the stages of building the model can be viewed at the following link:    • Tatra 813 Kolos 8x8 - Cross RC DC8 - stage...   ------------------------------------------------------------------------------- Technical data and used parts: Length: 784 mm, Width: 256 mm (with mirrors), Height: 253 mm, Weight: 10,7 kg/23,6 LB. (with Lipo 3S) Engine: Hobbywing QuicRun Fusion 540 1800kV Combo FOC 2-in-1 (brushless), integrated ESC 40/160A, Two-speed gearbox Cross RC, 12T rack on the motor shaft, Battery: Lipo 3S 11,1 V, ESC: integrated with the engine, Transmitter: Radiolink RC6GS V2, Receiver: Radiolink R7FG v1.3, Steering servo: two DS3235SG 180 ° 35 kg (Coreless Digital Servo) operates at 8.4 volts (from Cross RC 10A UBEC), Servo gears: DS3225SG 180 ° 25 kg (Coreless Digital Servo), Light module: Cross Rc LC3 + Das Mikro TBS Mini, Sound module: Das Mikro TBS Mini, 8Ohm 3W speaker. Varnish: Granit Quality Parts RAL 1028 + Boll clear varnish VHS (both two-component) + spray Deco Color Megafelga RAL9005. The cables at the lamps and the rear lamps have been taped with black silicone. Winch: worm gear motor JGY-370 12V 18 RPM, winch controlled by a small single-channel receiver and remote control for rc winches. Materials for the Das Mikro TBS Mini module: https://drive.google.com/drive/u/1/mo... My other projects can also be viewed on Flickr: https://www.flickr.com/photos/kolekcj... __________________________________________________ Camera: GoPro Hero 8 Black Video processing program: Open Shot Video Editor #crossrc #offroad #rc #truck #rcmodel #tatra #tatra813 #crossrcdc8
