DIY Automatic Trash Bin [Arduino and XOD]

Today we will make trash bin with robotized cap on Arduino! I used XOD to prototype this system. Learn more about XOD ► https://goo.gl/YaJkmm (launch IDE to open tutorial) XOD channel: https://goo.gl/5Spx6Z ★ Pass your hand to open the cap ★ Cap will not close while your hand is above the sensor ★ Cap will close some time after you remove your hand ★ Energy saving algorithm and hardware modifications allow this bin be in standby mode almost a year on 3 AA batteries! ► GitHub (scheme and sketch) https://github.com/AlexGyver/EnglishP... ► Components ✓ Arduino NANO http://ali.ski/POpMO ✓ Range sensor http://ali.ski/BOSn_x ✓ Servo http://ali.ski/N8P0y ✓ Battery holder http://ali.ski/D4tPxC ✓ Box http://ali.ski/GpYU7U ✓ MOSFET -IRF3704ZPBF -IRLB8743PBF -IRL2203NPBF -IRLB8748PBF -IRL8113PBF -IRL3803PBF -IRLB3813PBF -IRL3502PBF -IRL2505PBF -IRF3711PBF -IRL3713PBF -IRF3709ZPBF -AUIRL3705N -IRLB3034PBF -IRF3711ZPBF ✓ Resistor 100 Ом ✓ Resistor 10 кОм ✓ Highly recommend to use electrolytic capacitor 10V 470-1000 uF ► Page on Instructables https://www.instructables.com/id/Auto... ═════════════════════════════ ★ My website http://alexgyver.ru/ ★ Me on GutHub https://github.com/AlexGyver/EnglishP... ★ Me on Instructables http://www.instructables.com/member/M...
