Vu-Meter 20 LED DIY Dot/Bar mode with LM3915 and LM386

This is the "Perfect Vu-Meter" The best I've ever made. A Vu-Meter with 20 LEDs, two LM3915 and an integrated LM386 amplifier, it is also possible to connect a stereo signal to the input, and a graphical view with dot or bar mode.. This circuit is equipped with an audio transformer (TTC-167) that allows to separate the amplification circuit of the signal from the measurement one.. LM7809 takes care to keep the 9V voltage stable throughout the circuit. ► Features: 20 LEDs with *standard color scale LM3915 as LEDs driver LM386 as Amplifier 167-TTC Audio Signal Transformer Stereo Input (Low Level from RCA) Adjustable Gain LED Test button DOT & BAR mode 230V Power Supply *The standard color scale for a Vu-Meter is: 10 Green LEDs, 6 Yellow LEDs and 4 Red LEDs. Correct Electric Diagram: [EDIT 5 Ago 2018] - http://bit.ly/2EvjgjB In the video diagram the 1K resistor on LED 9 must be connected to the cathode (not anode) download the correct diagram from the previous link. PhotoSlide at: 5:25 Here I entered a Poll in the video ( 2:05 ) Please answer =) ► Components List: ● 2x LM3915 [ https://goo.gl/QWDhwu ] ● 1x LM386 [ https://goo.gl/WJZck1 ] ● 1x LM7809 [ https://goo.gl/2GCay4 ] ● 3x 1KΩ Resistor ● 3x 330Ω Resistor ● 3x 2,7KΩ Resistors ● 2x 10KΩ Resistors ● 2x 100KΩ Resistors ● 19x 120Ω Resistors ● 1x 1Ω Resistor ● 1x 50KΩ Trimmer ● 1x 2.5KΩ Trimmer ● 2x 1uF @ 25V Electrolytic Capacitors ● 2x 100uF @ 25V Electrolytic Capacitor ● 1x 470uF @ 25V Electrolytic Capacitor ● 1x 10uF @ 25V Electrolytic Capacitor ● 1x 100nF Capacitor ● 3x 1N4007 Diode ● 1x Audio Transformer TTC-167 [ https://goo.gl/doW21m ] ● 10x Green LEDs ● 6x Yellow LEDs ● 4x Red LEDs ● 2x LEDs any color as power LEDs ● 1x Switch (for Dot/Bar Mode) ● 1x Switch (for Leds test) ● 1x DIP 8 Pin ● 2x DIP 18 Pin ● 2x Heatsink for IC LM3915 [ https://goo.gl/2MkKTM ] ● 1x Heatsink for LM7809 ● 2x Female RCA ● 1x Box TEKO AUS12 [ https://goo.gl/vSxWHA ] ● 1x PSU 12V@1A [ https://goo.gl/nrKKzR ] ● 1x On/Off Switch (for 230V) ● 1x 230V Connector [ https://goo.gl/ameKXP ] ● 1x fuse holder (for glass fuse) ● 1x Glass fuse 500mA ● Stripboard ● Thermal paste [ https://goo.gl/kd2Uu6 ] ● 1x LED Socket [ https://goo.gl/MVVYe6 ] ► Similar videos: The Perfect Vu-Meter Breadboard:    • Vu-Meter with 20 LEDs with LM3915 - LM386 ...   Vu-Meter LM3915+LM386:    • Vu-Meter LM3915 + LM386 + TTC-167 with 20 LED   Vu-Meter 20 LED:    • Vu-Meter 20 LEDs with LM3915 (Standard LED...   Vu-Meter 100 LED:    • Vu-Meter 100 LED with 10x LM3915 - DIY   EMF Meter Detector:    • EMF Meter detector DIY | how to make it   ► Music: Vexento - Devotion (Intro) Vexento - Return Of The Heroes (Test) Vexento - Digital Kiss (Photo slide) ► More videos:    / stefano91ste   WARNING: This video is only for demonstration. I don't take any responsibility for damage to things, people and animals. ► My equipment: Panasonic HC-V180 (Main Camera) iPhone 6 (Secondary Camera) #ElectronicProjects #VuMeter #LM3915
