Polaris P825 - Zodiac WR000021 Robotic Pool Cleaner, Motor Housing rebuild Part 1.

also see Part 2 on the controller! This is a video on the P825 / WR000031 Robotic Pool Cleaner. just the Motor Housing ,wiring, motors. Tear down and rebuild. There are plenty of videos showing complete disassembly of Cleaner housing. The Cleaner would run Out of the water, Not in the water. If it turned on in the water it only ran a second and stopped. I took O Rings out of Housing- Long rectangle- and Motor contacts round. Just clean & re-lube and install. I did not use any Silicone or Gasket material.. ( You may choose to, ,, I just did as Factory did.)This way it can be rebuilt several times. The Motors will only seat one way with notches. Pull Middle motor out 1st. then Track motor. No real need to remove unless replacing. On the track Motor use a Thin wall 1 1/4" socket ( Huskey). "1" O Ring inside. Do not cut surrounding housing. "2" Nuts so just catch one at a time. The Impeller motor I used a 1 1/8" wrench. A deep socket can also be used. "2" O rings, In and out. All the screws are the Same Size for Entire Cleaner! Except, Small screw for Circuit Board inside Motor Housing. 2 Longer screws for Basket to motor Housing Under Gray Impeller Housing, DO NOT LOSE THE Shaft pin, to Track Wheel!!!!! It will fall out! The problems found were "2" Wiring was broke and corroded (inside Casing)close to where it enters cleaner. I just bent wiring and could feel the break. This was the rewire on video. ( I will try to post still pictures of the wiring and Plugs if able. I 1st Soldered wires, Then redid and used watertight heat shrink butt connectors, Then Shrink wrapped each wire, Then used 1/2 " Shrink wrap over all the wires to inside cleaner. Used original Plug - Good on 1 housing. I also Tie Wrapped wires around post inside to help with Pulling. ( Not sure Why a clamp was not installed at Factory?) The other is the Control unit. One does not work, the 2nd ( Have 2), I must start & stop with second one several times. When it starts it runs great! I'll tear down and check the bad one, If issue found I'll post. After Completing it did Work & Still Working!!!! I do have a few Still pictures of some of the rebuild and Wiring, I will try and add here Or make a part 2... Not sure How yet... Do You? PS; Not responsible for Any Electrical Shocks, Cut / Smashed Fingers, Thrown Tools etc!! This is a really simple rebuild. CHECK the WIREs! Just make sure you Water Proof, Shrink Wrap Everything! Clean Contacts, Too! I do Rebuilds for Fun of it... Especially when I'm told it can't be done. I Just redid a EGO Mower speed control issue. I'll put a video of it when time permits!! Any Comments or questions Please Ask! Thanks for viewing... "Tug" Over ~n~ Out! Dog the Hatches!
