DC and DCC Block Occupancy Detection in Action

Happy New Year! This is the second part of my series on block occupancy detection using an Arduino and ACS712 sensors. The test loop is now fairly functional with a turnout operated by a servo, block occupancy detection and a prototype of the signal system I'll be using on the Lassen & North Coast Railroad. On the test loop a single Uno with an Ethernet shield does all the work; it communicates with my simple touch screen control panel (See "A Programmable Layout Controller" at http://thenscaler.com/?p=414) for turnout commands and block occupancy status data. For more information and discussion relevant to this video, see the blog entry at http://thenscaler.com/?p=529.
