IndraDrive – Setup SafeMotion for only Safe Torque Off with Safe Stop 1

Applications that use a fieldbus protocol with safety protocol may have motion axis that only require the functionality: Safe Torque OFF (STO), or Safe Stop 1 (SS1) / Category 1 Stop In this video we will demonstrate how to configure an IndraDrive with SafeMotion (SMO) connected via fieldbus with safety protocol but using only the Safe Torque Off (STO) with Safe Stop 1 (SS1) / Category 1 Stop and no other SafeMotion functions. For an easy setup, you can obtain the preconfigured safety parameter file (.par) inside of “STO Only Starting Parameter R1.zip” located under “Downloads” in this ctrlX Community How-to link: https://developer.community.boschrexr... Video content: 00:04 Introduction 00:18 Reference information 00:31 Architectures for only STO when using SafeMotion (SMO) on a fieldbus network 00:35 IndraDrive family overview 00:41 Cabinet free drive IndraDrive Mi - SafeMotion hardware options 00:47 Cabinet installed IndraDrive - SafeMotion hardware options 00:52 Software and firmware versions 00:58 General IndraDrive configuration using the file “STO Only Starting Parameter R1.par” 02:16 Configure the target UIND for safety bus communication in three steps 03:43 Overview of all IndraDrive safety bus communication protocols 03:58 Setup - CIP Safety on Sercos (CSos) automation bus 04:34 Setup - FailSafe over EtherCAT (FSoE) 05:13 Setup - PROFIsafe over PROFINET 05:52 Setup - CIP Safety over Ethernet/IP (CSoE) 06:38 Programming example using a safety PLC 07:23 HSZ Zone Module Configuration and I/O Mapper example 08:21 Local I/O Configuration and I/O Mapper example 09:31 Error reaction mode observations 10:27 Exit SMO Configuration and Parameter Mode Downloads: www.boschrexroth.com/en/us/search.html?s=download&q=&num=50 Find the free IndraWorks commissioning software by searching for “IndraWorks Ds” and under the Download tab choose the latest 15Vxx version. Find the documents by searching for “R911xxxxx” and under the Download tab choose the document: SMO with only STO with Safe Stop 1 V3.pdf – video support document with the parameter file “STO Only Starting Parameter R1.par” R911338920 - IndraDrive Safe Motion R911385758 - IndraDrive Firmware MPx21 Functions R911345608 - IndraDrive Firmware MPx20 Functions R911328651 - IndraDrive Parameter Description R911326738 - IndraDrive Information on troubleshooting IndraWorks Ds How-To Video:    • IndraWorks Ds – connect to IndraDrive via ...   Ethernet/IP communications with Allen-Bradley PLC AOIs: https://bit.ly/3ztYO0q Full playlist at:    • Electric Drives and Controls Product Support   Follow @boschrexroth Bosch Rexroth Facebook:   / boschrexrothus   Bosch Rexroth Twitter:   / boschrexrothus   Bosch Rexroth LinkedIn:   / boschrexroth   Bosch Rexroth Instagram:   / boschrexrothus
