Stability Analysis of Power Supplies with the Bode 100

Note: We have a new and extended video on this topic! Check out:    • Stability Analysis of Power Supplies   In this video tutorial we show how the vector network analyzer Bode 100 is used to perform stability analysis of a linear voltage regulator. We use the Bode 100 in conjunction with the B-WIT 100 wideband injection transformer to measure the open loop gain of a LM317 linear voltage regulator and read out the gain margin and the phase margin. By demonstrating the measurement of the stability of the DC power supply some nice features of the Bode Analyzer Suite like the shaped level function are shown. The shaped level function allows changing the output signal level of the Bode 100 over frequency. This allows to reduce noise where necessary, but to keep the level low in order to not overdrive the control loop. The VNA Bode 100 can be also used to visualize the influence of input voltage and load current changes on the stability of a control loop. To gather further information about the methods used to measure quality indicators of a DC power supply containing DC/DC converters please download our application note at: http://www.omicron-lab.com/bode-100/a... Used Measurement Equipment: Bode 100 -- The Bode 100 is a vector network analyzer that serves as a frequency response analyzer, a gain phase meter and impedance meter as well as a sine wave generator. It can be controlled via the Bode Analyzer Suite, a graphical user interface. An OLE compatible automation interface allows easy implementation into automated systems. B-WIT 100 -- The wideband injection transformer B-WIT 100 is used for inserting signals into a high variety of electronic circuits such as control loops or switched mode power supplies. Picotest J2111 Solid State Current Injector -- The J2111 Solid State Current Injector is used to inject currents into electronic circuits and work as an ac current load (e.g. for output impedance measurements) More information at: http://www.omicron-lab.com
