#11 Flip-flops, Counters & Digital Dice - How to use Breadboards & Retro Digital Electronics

What are solderless breadboards and how can you use them to build and learn about retro microcomputers and digital electronics? The eleventh in the series covers flip-flops and counters and we use these to build a simple digital dice/die. These are also used for retro microcomputer projects using one of Z80, 6502, 6800, 6809, 8088 and 68000. Chips used include 74LS74, 74LS92, 74LS163 and 74LS247. Ben Eater Videos on SR Latch & Flip Flops    • SR latch   Texas Instruments (TI) Digital Logic Pocket Data Book https://www.ti.com/lit/sl/scyd013b/sc... Chapters 0:00 Introduction 1:27 SR Latch 3:27 SR Latch breadboard circuit 5:20 D-Type Flip-Flops 8:32 D-Type examples 10:18 74LS74 D-Type Flip Flop 11:15 74LS74 breadboard circuit 17:05 74LS174 & 74LS175 Flip-flops 18:35 Ripple Counter 20:00 74LS92 Counter 21:28 74LS92 breadboard circuit 24:08 74LS163 Synchronous Binary counter 25:30 74LS163 breadboard circuit 28:25 Digital Dice/Die 32:06 Summary and next video
