SOLIDWORKS TUTORIAL : click ballpoint pen with spring

Welcome to the copycat meowmeow channel! We know the pen is a widely used tool on this earth. As children, we were taught how to write with a pen/pencil. A pen is a type of tool that has a liquid called ink used for writing. There are various forms of pens available in the market, but their functions remain the same. So, do you know what is in the pen you are using ?. The pen has several components, among them, the ink rod, the ink tip, the spring for the upper click pen, the cover for the pen using the cover, and the body of the pen itself. In this tutorial, Copycat meowmeow selects a click-through pen to model it using Solidworks. This way, you can learn how the pen is modeled, and also you will know the internal components of the pen. Among the commands used in modeling this pen are, revolve boss (00:00:43) intersection curve (00:05:48) extrude cut (00:06:25) revolve cut (00:09:21) linear pattern (00:11:08) loft boss (00:11:54) change material (00:29:05) helix and spiral-variable pitch (00:29:47) -with on screen keyboard sweep boss- spring (00:33:25) assembly parts (01:02:00) float a part in assembly mode (01:02:28) fix parts in assembly mode (01:02:46) mate the part (01:03:00) compress the spring (01:08:00) Please visit this page to see some interesting copycat meowmeow projects   / amriyobiz   To own this model, please go to this link, https://www.cgtrader.com/3d-print-mod... Please don't forget to subscribe, like, and share.
