8-25mmx2800mm CTL Heavy Gauge Cut To Length Lines

Cut To Length line is a high efficient metal processing production line for cutting metal flat sheet from metal coils. The metal coils unwind, leveled, cut to length and blanking. LONGAR supply full range of cut to length line China according to client’s special requirement by combining different component. Every CTL line is engineered and constructed differently for customers, it is customized designed and built, it is considered when choosing a right CTL line about some specifics like production capacity, running speed, material thickness and width, etc. Quality and standard checks are strictly performed on our product before releasing to our valued customers. Available raw material for cut to length line is hot rolled steel, cold rolled steel, galvanized steel, pre-painted steel, high tensile steel, stainless steel, aluminum, copper, alloys. The whole line consists of coil car, double support uncoiler, hydraulic pressing and guiding side device, shovel head, pre-leveler, high precision leveler, cut to length machine, stacker, electric control system, hydraulic system, etc. as well as pendulum middle plate and steering device. Main Technical Parameters of Heavy Gauge Cut To Length Lines 1.Coil properties: δs≤550MPa, δb≤600MPa 2.Coil thickness: 8mm-25mm 3.Coil width: Max. 2500mm 4.Coil I.D: 508 mm 5.Coil O.D: Max. 2500 mm 6.Coil weight: 40000 kg 7.Line speed: 0-25 m/min 8.Leveler shaft diameter: 260 mm 9.Leveler rollers quantity: 9 10.Cutting length: 800-12000 mm 11.Cutting rate: 8 pieces/min 12.Length tolerance: ±1 mm 13.Diagonal tolerance: ±2 mm 14.Straightening tolerance: ±2 mm/m2 15.Total power: about 250 KW 16.Total weight: about 80 T LONGAR heavy gauge cut to length lines are built for speed and ease of use and can produce higher line speeds without experiencing material slippage. Cut-To-Length Line and Blanking Line will make your job easier, cut costs, and increase your profits. The lines can be supplied with start-stop shears, flying shears. For start stop shear, the sheet is stopped for each cut of the shear. They can cut a variety of lengths and thicknesses. Electric controls are used to stop the leveler drive after the required length has been fed through the shear and to initiate shear action, then the subsequent feeding of the sheared length to the stacker. For flying shear, it’s a high production solution Here is working process: Steel coils are transferred by an entry coil car and loaded onto an uncoiler. From uncoiler the strip proceeds through a five-high precision leveler designed to level steel within the desired material gauge range and yield strength. The strip then proceeds through a squaring unit and precision roll-feed unit to the high speed shear, where it is cut to required length. The cut sheet then moves to float sheet stacker where it is stacked on a pallet and is then moved onto the semiautomatic packaging line for wrapping. Benefits of LONGAR Cut to Length lines Minimal tooling preparations and higher productivity rates Energy efficient Reduced operating costs High in speed and strength High input and output rates Extreme sheet flatness due to high precision levelers Exact cutting accuracy Suitable for manufactures of Pipes and Tubes Seamless Pipes & Tubes Welded Pipes & Tubes ERW Pipes & Tubes EFW Pipes & Tubes U Bend Pipes & Tubes Capillary Tubes Sheets and Plates Shim Sheet Perforated Sheet Chequered Plate Strip & Foils Flats & Coils Profile & Ring cut to length services slitting services pipes & tubes rectangle hollow square hollow round hollow coils hot dipped steel cold rolled steel Contact Project Manager: Jean Sun Wuxi LonGar Machinery Manufactory Co.,Ltd Add: No.3, Xian Feng Middle Road, Xi Shan District, Wuxi City, Jiangsu Province, China http://www.wxlongar.com www.coilslitter.com Tel:+86 510 82698581 Fax:+86 510 82610322 Mobile(whatsapp):+86 15298417602 Wechat: Jean101488 Mail ID: projects@wxlongar.com
