Drawing Shear and Moment Diagrams - Beam With Hinges Example [2/3]

📌 Read the complete shear and moment diagram tutorial and download all PDF worked solutions free on EngineeringSkills.com 🔗 https://www.engineeringskills.com/pos... In this video, we work through the analysis of a statically determinate beam that has multiple internal hinges. In this example, you’ll learn how to use the internal hinges to break up the structure into sub-structures in order to calculate the reactions. We’ll introduce the technique of ‘tracing the loads across the structure’ in order to rapidly draw the complete shear force diagram. Then, you’ll learn how you can use the shear force diagram as a guide to sketch out the qualitative bending moment diagram. Finally, we’ll make discrete cuts in the beam to identify the remaining unknown bending moments and complete the full bending moment diagram. This multi-step approach allows us to draw shear and moment diagrams quickly and accurately. This is part 2 in a 3-part series on mastering shear and moment diagrams. Find parts 1 and 2 here… Part 1 ➡️    • Drawing Shear and Moment Diagrams - Simple...   Part 3 ➡️    • Drawing Shear and Moment Diagrams - 2D Fra...   Timestamps 00:00 Intro 01:11 Calculating reactions 06:18 Explaining the technique 08:59 Constructing the shear force diagram 16:38 Sketching the bending moment diagram 25:48 Recap of shear and moment diagrams 27:23 Calculating bending moment at C 28:29 Calculating bending moment at E 29:31 Local maximum bending moment 30:36 Recap and wrapping up
