10 HP 2800 RPM Motor Rewinding Formula | 3 Phase Motor Practical Data

10 HP 2800 RPM Motor Rewinding Formula | 3 Phase Motor Practical Data ‪@AffanElectricSolutions‬ ‪@windertrucker6230‬ ‪@linguoermechanic‬ ‪@Alitechwork‬ ‪@GurjinderElectricWorks‬ In this video, I am sharing the complete practical rewinding formula of a 10 HP, 2800 RPM, three phase induction motor, taken directly from workshop calculation. This video is very useful for motor rewinders who want accurate and tested data for high-speed three phase motors. 🔹 Motor Specifications: Power: 10 HP Speed: 2800 RPM Voltage: 440 V Phase: Three Phase 🔹 Stator & Winding Data: Total Slots: 30 Coils per Set: 2 + 3 Total Sets: 6 🔹 Pole Pitch Formula: Pole Pitch = (12 + 14) / (12 + 14 + 16) 🔹 Wire & Copper Details: Wire Gauge: 20 SWG + 20 SWG (Parallel) Copper Weight per Set: 1060 g + 1120 g Total Copper Weight: 5478 g (Approx 5.5 KG) 🔹 Connection: Series + Delta This formula is based on real workshop experience and helps ensure: Proper motor performance Correct current balance Long motor life #10HPMotor #2800RPMMotor #ThreePhaseMotor #MotorRewinding #MotorWindingFormula #ElectricMotor #IndustrialMotor #MotorRepair #RewindingFormula
