Semi Automatic Glass Bottle Washing Machine

This is a compact washing machine for glass bottles. It is made of SS 304. It consists of a brushing unit mounted on one side of the machine. The unit has 4 brushes. An extra set of mouth cleaning brushes are also provided. The brushed bottles are then kept upside down on the adjoining rinser trays which are of plastic. These trays can hold 24 bottles. Once the tray is full, it is manually pushed and it goes to the next place where the bottles are rinsed with high speed jets of water. For this two 1/2 Hp pumps are provided. The machine can hold 6 trays in a row. The bottles are rinsed two times one after the other. The rinsed water falls back into the plastic bin at the bottom and is recycled. The bin can hold about 100 litres of water. It is provided with water inlet and outlet ball valves.
