Tech Tip: Adjusting Ebody Actuator Orientation

Hi, I’m Eric Williams, Valve Assessment Specialist at Automation Service. I’m here to give you my Two-Cent-Tech-Tip. Something that many people have questions about is Ebody actuator orientation. This is something we run into when a customer wants to turn around their positioner the opposite direction from our standard orientation. For a 667 Air to Open actuator, the right way to change the orientation is to first raise the valve plug off the seat by applying air to the actuator, loosen up the Yoke Nut and turn the whole actuator 180 degrees. Then tighten back up the Yoke Nut, and you can release the air to bring your valve plug back down to the seat. For a 657 Air to Close actuator, with air pressure released from the actuator, all you have to do is loosen up the Yoke Nut and turn it. Then tighten the Yoke Nut down again. Without following the proper procedure to change the orientation, it’s possible to end up damaging the seat and the plug. That’s my two-cents! If you have any questions, please give us a call at 800-325-4808. And don’t forget to check back on our website and social media channels for future Two-Cent-Tech-Tips! ========================== YOU MIGHT ALSO LIKE → Need help calibrating your DVC6000? Click here to download our free calibration instructions: http://go.automationservice.com/dvc60... If your plant is interested in a flow meter, click here to submit a quick quote request: http://www.automationservice.com/prod... ========================== RECYCLE→ Is your manufacturing plant as green as it can be? Take a look at our process controls recycling program. Our program is completely personalized and HASSLE FREE. Your department can earn credits toward future purchases of remanufactured process controls and Fisher® valves. We also reward your team for participating with our fun (and tasty) Reclamation Road Trip program. Click here to learn more: : http://go.automationservice.com/learn... ========================== CONNECT WITH US→ Youtube Subscribe:    / subscription_.  . Facebook:   / automation-s.  . Twitter:   / reman_controls   LInkedIn:   / company-beta.  . ========================== Automation Service is the world’s largest remanufacturer of high-quality process controls. We are internationally recognized as the leading supplier of remanufactured transmitters, control valves & actuators, regulators, flowmeters & flowtubes, controllers, positioners, capillaries & sealed systems, transducers and more. We remanufacture products originally manufactured by Rosemount®, Fisher®, Foxboro®, Honeywell® and Moore®, and are proud to say that our products are “Re-Made in the USA.” Automation Service http://www.automationservice.com Contact us: http://www.automationservice.com/cont... Automation Service is the sole warrantor of this product and is NOT affiliated or endorsed by Fisher, Rosemount, or any other Emerson Process Management Company. Automation Service is not an FM Approved Repair Facility and cannot supply remanufactured or repaired FM Approved equipment for Hazardous Locations.
