E3D Toolchanger - UPGRADES #02 - double PSU

Since over a year, I had planned to mount one more PSU into the Toolchanger. To do so, I’ll replace the rather big and loud generic PSU and replace it with 2 passive – and silent – PSU’s that are smaller in size, too. You may ask: “But why?” The answer is straight forward: For the #ASMBL-tool, that is build out of readily available model flight equipment, I need 12V to drive it. So a 12V PSU additionally to the 24V PSU in the ToolChanger is needed. Because of the experience with my #beta30 ToolChanger I knew, that these PSU are reliable and very easy to integrate into the electronics compartment. For the tutorials on the ToolChanger I need to do the electronics easy and safe. So I sat down and designed & printed some nice terminal mounts for the reliable WAGO 221 terminals. 📖Website article: https://rene-jurack.de/double-psus-wi... 🤝Please support me:🤝 buy a ToolChanger: https://geni.us/ToolChanger Patreon:   / renejurack   PayPal: https://www.paypal.me/renejurack ⚙️🛠Additional parts and tools used (affiliates): Meanwell HLG-320H 24V@320W: https://geni.us/Meanwell320W Meanwell HLG-80H 12V@60W: https://geni.us/Meanwell12V60W WAGO 221: https://geni.us/WAGO221 WEIDMÜLLER Stripax: https://geni.us/stripax KNIPEX pliers: https://geni.us/KnipexPliers WERA L-key color: https://geni.us/WeraLkeys WERA micro hex screwdriver set: https://geni.us/WeraMicro ℹ️All files and printed parts shown are available for download here: https://rene-jurack.de/double-psus-wi... 📖All my designs & files at https://www.rene-jurack.de 🔗usefull links: E3D-Wiki: https://e3d-online.dozuki.com/c/ToolC... Facebook-Group about Toolchangers:   / 237615240416855   E3D-Discord with TC-Channels:   / discord   00:00 - Introduction 01:06 - Intro 01:18 - mounting the PSUs 03:50 - mounting the terminals 08:35 - connecting the PSUs 12V & 24V 09:10 - connecting the PSUs mains 11:46 - connecting the DUET 12:33 - connecting the SSR 13:02 - outro & credits Music by Epidemic Sound https://www.epidemicsound.com/referra...
