Overcome Text Line Challenges in AutoCAD

Simple line type is a combination of lines and text, whereas complex line type contains complex shapes. Steps to create simple line type 1. Go to Express Tools - Make Line type 2. Give line type a file name; Gas line.lin. If you need to load a line in the line type list, this file .lin is used. 3. Give Line type name; GAS Line type. You will see this name in the line type list. 4. Next, Line type description 5. Specify starting point and end point 6. Select object Select the line and text and hit enter. 7. Line type is created and it should be displayed in the line type drop down list. https://www.bimlane.com/ MEP CAD & BIM SERVICES Please contact +9189217521895
