How to assembly and install the hydraulic piston pump use the spare parts of Elephant Fluid Power

ELEPHANT FLUID POWER CO., LTD brings new life to old hydraulic pumps with new hydraulic pump accessories. Allow users and hydraulic maintenance companies to get fast service, save money for users and people, and allow hydraulic service companies to bring better profits and improve timeliness. ELEPHANT FLUID POWER The perfect hydraulic service expert, with a technical and service team As a professional manufacturer of hydraulic piston pumps and accessories, when you buy our company’s products, we will provide you with a high-quality customer experience, which of course includes helping you install the piston pump, so If you buy from other pump manufacturer and they don't provide piston pump installation services, don't worry, just let the excellent piston pump manufacturer(Elephant Fluid Power) tell you the eight steps, so that you can easily install the axial piston pump yourself 　　 1. Assemble the drive shaft components. Install two small bearings and inner and outer spacers on the shaft neck of the drive shaft and lock them with elastic retaining rings; 　　 2. Assemble the drive shaft and the pump body. Axial piston pump manufacturers kindly remind: After checking the end face of the pump body, especially the flatness and roughness of the end face combined with the oil distribution plate, install the drive shaft components into the pump body hole, and when the shaft is required to rotate The end face runout amount is not more than 0.03, and then install the oil seal cover (round flange) on the end face of the pump body; 　　3, butt the pump body and pump casing. Place the pump body vertically with the protruding end of the drive shaft down, and place it firmly with a high cushion. When connecting the pump body and pump casing with screws, pay attention to the integrity of the large and small sealing rings, especially the small sealing ring at the pressure control oil passage interface; 　　 4. Install roller bearings. Pay attention to the uniform force of the bearing; 　　 5. Place the oil pan. Pay attention to the oil distribution plate to be placed flat, you can tap it with a thin copper rod (vertically leave a certain distance and fall freely), the sound should be crisp; 　　6. ​​Place the cylinder. Hoisting screws should be used above 160; 　　7, put the outer jacket, center spring, inner sleeve and steel ball in sequence; 　　 8. Put the plunger and the shoe assembly on the return plate, and then put it vertically into the cylinder. 　　 After listening to the introduction of the Elephant fluid power piston pump manufacturer, did you find that the installation steps are actually very simple? If you need other help, please contact Elephant Fluid Power. If you would like know more details,pls check our website: www.heavyequipmentmaintain.com Or contact me with email:[email protected] Whatsapp:+8618732165173
