The New Rutronik Development Kit - RDK2 for firm- and hardware designing

First choice for the RutDevKit was Infineon Cypress’ microcontroller PSoC62. It is built on an ultra low-power platform (40-nm) and combines an Arm® Cortex™-M4 and Arm Cortex-M0+ CPUs with low-power Flash technology, programmable digital and analog resources, and offering high- performing CapSense technology. Built around the PSoC62 are best fitting standard components in order to offer the highest level of benefit and access to all the comprising features of the microcontroller for customers. Interested in Rutronik´s development kit? Go to https://www.rutronik.com/devkit The board's new and unique butterfly design allows for improved handling and user-friendly access to the Arduino connectors and reduces potential interference from electromagnetic effects, especially with RF IoT Arduino Shields. The integrated potentiometer can be used for testing the analog-to-digital conversion. A special feature is that the user can access all pins of the PSoC62 via supplied headers. In addition, a capacitive sensor technology has been installed, the so-called Cap Sense. This enables a touch area that can be used as a slider. All components of the BOM can be found in the Rutronik portfolio. Like its predecessor board RutDevKit-STM32L5 the RutDevKit-PSoC62 offers a complete solution for hardware and firmware developers and a basis for a modular toolkit, so that proof of concepts can be created in a very short time. The RutDevKit is especially designed for touch and proximity applications in the fields of Internet of Things as well as Industrial IoT (IoT, IIoT), smart wearables, smart home, medical devices, etc. It is run on the PSoC62 MCU by Infineon. The microcontroller has a dual core CPU and is therefore ideal for secure edge computing and cloud applications. The PSoC62 has an integrated power management IC for SMPS for all connected power supplies.y
