This movement demonstrates one of the different arrangements of pulleys in a compound system. In such a setup, each pulley is engaged by a rope that is anchored at one end to a fixed point and attached at the other end to the center of a movable pulley. The overall mechanical effect depends on the number of movable pulleys in the system, with each movable pulley effectively doubling the mechanical advantage according to the principle described in the 507 collection. Different configurations illustrate how force and motion change with various pulley arrangements. 3D visualization of mechanism from the classic engineering reference "Five Hundred and Seven Mechanical Movements" by Henry T. Brown. Description: Illustrates the transmission of power by simple pulleys and an open belt. In this case both of the pulleys rotate in the same direction. About this Project: I am recreating all 507 mechanical movements in high-quality 3D animations. This library serves as a visual guide for engineers, students, designers, and hobbyists to understand kinematics and mechanical design. Support the Library: If you find these visualizations helpful, please subscribe to follow the progress as I complete all 507 movements. #MechanicalMovements #Engineering #Mechanism #Kinematics #IndustrialDesign #507Movements
