Section Roller SM-PK10PWR

For more info visit www.assetplant.com SKU 23-0604PWR Description This European designed section - ring roller will partner you through all your rolling applications. 240V powered operation. complete with stand, this handy roller is also fantastic value for its price. Features ❚heavy duty steel fabricated fame ❚manual adjustment of top roller ❚side supports on all models ❚calibrated scale for roller adjustment ❚one piece guiding mono block mounted on cross head ❚powered hardened 98mm top & 118mm bottom rolls ❚standard flat & angle rolls are included ❚bottom rolls are knurled for additional grip on material ❚additional dies are required to roll round bar, round pipe/tube & square tube ❚CE compliant Includes ❚standard section rollers and spacers Technical data ❚pipe capacity – 30mm / min. dia.– 700mm ❚tube capacity – 32mm x 2mm / min. dia.– 800mm ❚angle iron capacity – 30mm / min. dia.– 760mm ❚solid capacity – 20mm / min. dia.– 500mm ❚flat bar (easy way) – 50mm / min. dia.– 300mm ❚flat bar (easy way) – 19mm / min. dia.– 400mm ❚top roll diameter - 98mm ❚bottom roll diameter – 115mm ❚dimensions - 600mm x 600mm x 1750mm ❚weight - 230kg
