EMI207 - Arbitrary Waveform Generator (AWG)

Arbitrary Waveform Generator (AWG) An arbitrary waveform generator (AWG) is a piece of electronic test equipment used to generate electrical waveforms. These waveforms can be either repetitive or single-shot (once only) in which case some kind of triggering source is required (internal or external). The resulting waveforms can be injected into a device under test and analyzed as they progress through it, confirming the proper operation of the device or pinpointing a fault in it. Unlike function generators, AWGs can generate any arbitrarily defined waveshape as their output. Function Generators Including Sine, Square, Triangular, Pulse and Ramp signals. Advanced Functions Multi-tine, AM/FM, cardiac, Gaussian Pulse, noise and others Arbitrary Waveforms Point-to-Point user-defined waveforms. Arbitrary Waveforms is defined as a waveform that doesn’t have a predefined shape or characteristics, its amplitude and frequency can be varied in random manner. It poses periodicity at sometimes and non periodicity at other times. It is digitally based signal source capable of generating any waveform within published limits of bandwidth, frequency range accuracy and output level. Arbitrary waveforms are used to test the signals. Arbitrary waveforms also used to generate digital signals. Arbitrary waveform Generator stores the digital data in RAM. It detects any faults. Proper functions are available.
